Power Nickel-metal Hydride Batteries

This series of products are suitable for models, toys, tools or electronic equipments that require high current discharge, such as electric car models, boat models, air models, catapult toys, mixers and so on.



Electrical Characteristics:

Charging current: standard ~0.1C/fast ~0.5C
Charging time: 0.1C*12hrs(standard)/0.5C*2.5hrs(fast)

Standard charging method: Constant current (CC) charging / 0.5C or more whisker-ΔV control

Maximum charging current*: 1C/0.2c below 10°C

Discharge cutoff voltage*: 0.9V/string | normal multiplier 1.0V/string

Minimum storage voltage: 1.2V/string, otherwise it should be recharged in time.

*Voltage value multiplied by the number of cell strings when connected in series/current multiplied by the number of cell parallels when connected in parallel; operating current whichever is the smaller parameter.

*Specialized chargers must be used! Use of non-standard chargers may not achieve the effect of use or even damage the battery.



Temperature Characterization:
Charging: 0~45℃ Discharging: -10~55℃ Storage: -20~35℃

Relative humidity: 45~85%

Series Typical models
1S 1.2V AA 2/3A
2S 2.4V AAx2 2/3Ax2
3S 3.6V AAx3 2/3Ax3
4S 4.8V AAx4 2/3Ax4
5S 6.0V AAx5 2/3Ax5
6S 7.2V AAx6 2/3Ax6
7S 8.4V AAx7 2/3Ax7 2/3Ax(3+4)
8S 9.6V AAx8 2/3Ax8 2/3Ax(4+4)
